Rear dumper semi trailer
Tare weight
8000kg-10000kg
Size
8500-11500mm*2500mm*2500mm-3600mm
Payload
30T-70T
Main beam Heavy duty and extra durability designed I beam; opting for high tensile steel Q3 45, welded by automatic submerged-Arc processes. Top flange 18mm,width140m m;Middle Flange 14mm height 500mm;bottom flange20mm,width 140m m
Floor
4mm/6mm/8mm/10mm
Side wall
Height 1000mm-2100mm thickness 3mm/6mm/8mm
Cylinder
HYVA or china brand model according design
Axle
2/3 axle FUWA/BPW/SAF/L1 brand or China local brand 13T/15T/16T
Suspension
Mechanical suspension (brand optional)
Leaf spring
Leaf spring 10pcs*90*13mm
Tire
11.00R20/12.00R20/11R22.5/12R22.5/825R20/385/65R22.5 Tire optional
Wheel rim
8.5-20/9.0-20/8.25-22.5/9.0-22.5/9.75 wheel rim optional upon choice
Kingpin
JOST or other brand 2" /3.5" bolt-in king pin
Landing gear
JOST or other brand two-speed, landing gear 28T
Vehicle application
Sand stone coal transport
Braking system
WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
ABS
Optional
Light
LED 8 side lights and 2 rear lights 2 width lamp
Painting
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint
Accessories
One standard tool box, one spare tire carrier, one crank, one shaft head wrenc h, four side light, two rear light
