Crawler bulldozer SD16

for construction

Configuration selling point Shantui’s self-manufactured drive system perfectly aligns with the engine curve, resulting in substantial traction and enhanced transmission efficiency. Shantui’s self-developed four wheels and one track are built to be durable; Ease of maintenance and operation comfort The openable side guard offers a spacious area and the reasonable layout of filter elements facilitates convenient maintenance. The hexahedral cab is designed with ergonomic considerations and provides a spacious interior and wide field of view. Adaptability to diverse working conditions The machine is equipped with a straight tilt blade for enhanced cutting force, making it well-suited for diverse working conditions such as clay, frozen soil, and sandy soil. The chassis system is stable with large ground clearance, demonstrating excellent passability; Engine brand - WEICHAI WD10G178E25 Machine external dimensions(mm) - 5140*3455*3032 Track center distance(mm) - 1880 Track shoe width(mm) - 510/560/610 Ground contact length(mm) - 2430 Fuel tank capacity(L) - 315 Blade type - Straight tilting/U-shaped Blade Blade capacity(m³) - 3.2/4.8 Emissions (Indicated as per international standards) - Eu stageⅡ
