Configuration selling point
With the mechanically-driven automobile gearbox integrating a synchronizer, it is light for gear shifting; the hydraulic vibration, single frequency & single amplitude and large excitation force guarantees excellent compaction performance; with the hydraulic steering and articulated frame, it is light and flexible in steering;
Ease of maintenance and operation comfort
The rear hood can be opened at a large angle for easy maintenance; the standard cab can be fitted with optional dual-purpose air conditioner.
Adaptability to diverse working conditions
It is suitable for the compaction of engineering foundations of the highways, urban and rural roads etc., and can compact non-adhesive materials such as sand, gravel, crushed stone and semi-adhesive materials
External dimensions(mm) - 5130*1830*2570
Engine brand - Xinchai
Front and rear load distribution - 3850/4150
Vibration frequency low/high(Hz) - 42
Minimum turning radius(mm) - 5500
Excitation force(kN) - 85
Amplitude(mm) - 0.7
Gradeability - 0.25
Speed(km/h) - For:2.2/4.2/7.5/12.5/15.5;Rev:2.5
Emissions (Indicated as per China standards) - Eu stage II
