Diaphragm pump ADKwaterwith electric motorself-priming
Add to favorites
Compare this product
Characteristics
- Technology
- diaphragm
- Fluid
- water
- Operation
- with electric motor
- Priming
- self-priming
- Mobility
- mobile, stationary
- Domain
- industrial
- Applications
- service
- Other characteristics
- multi-stage, mechanical, axial, seal
- Flow
Min.: 40 m³/h
(1,412.58667 ft³/h)Max.: 1,000 m³/h
(35,314.66672 ft³/h)- Head
Min.: 100 m
(328'01" )Max.: 1,500 m
(4921'03" )- Power
Min.: 15 kW
(20.39 hp)Max.: 2,000 kW
(2,719.24 hp)- Fluid temperature
Min.: 0 °C
(32 °F)Max.: 100 °C
(212 °F)
Description
The structural type is multi-stage split-casing pump ADK series;
The impellers are back to back symmetrically arranged, which offsets the axial force of rotor so that the service time of the bearing can be extended.
Shaft seals at two ends are mechanical seal.
Pump and electrical motor are connected with a flexible diaphragm coupling with an intermediate segment. Under the condition that the intermediate segment of the coupling is dismantled, bearing and mechanical seal can be examined or maintained without moving the electrical motor.
