Compression testing machine HL-GQC series

automaticfor cablesfor the optical industry

Optical Fiber Cable Crush Cut Tester complies with employs an IEC-60794-1-2 Method E3/E12 to perform compression (Crush) test on optical cables. Cable is laid to rest under compression as per detailed specifications, and then the attenuation of fiber optics is measured. It employs servo-controlled system to apply compressive force on the cable in constant speed and maintains the compression force in specified period. Crush Load capacity 5KN/10KN Crosshead travel 600 mm Loading speed 0.01 – 500 mm/min Displacement measuring accuracy ±0.3% Position measurement accuracy ±0.01% of reading or 0.0001 mm, whichever is greater
