Centrifugal pump

waterwith electric motorstationary

W single stage close coupled peripheral pump is used for delivering clean water and liquids similar with water in physical and chemical properties. Liquid temperature should not exceed 60°C. It is often used for the boiler water supply facilities, metallurgy, machinery manufacturing, water aquaculture production, fixed fire-fighting constant pressure systems, heat exchange systems, remote agricultural irrigation etc. >>>Working Conditions · Max working pressure is less than 1.6MPa, which refers to the inlet pressure and the outlet pressure all together is less than 1.6MPa. · Proper medium: clear water without solid particles or the solid particle content is no more than 0.1% of the water and diameter is less than 0.2mm · The environment temperature should not be higher than 80℃. The relative humidity should not be more than 95%. >>>Applications D series horizontal centrifugal pump is used to deliver clear water and other liquids similar to water in physical properties for industrial and cities water supply and drainage, high buildings booster water supply, garden irrigation, fire fighting booster, remote watersupply, warming systersm, cycle booster of cold and hot water bath rooms as well as for industrial equipments.
