Absolute pressure transmitter PAS100
strain gauge4-20 mAHART

Absolute pressure transmitter - PAS100 - Shanghai Powerbuilder Automation Technology Co. Ltd - strain gauge / 4-20 mA / HART
Absolute pressure transmitter - PAS100 - Shanghai Powerbuilder Automation Technology Co. Ltd - strain gauge / 4-20 mA / HART
Absolute pressure transmitter - PAS100 - Shanghai Powerbuilder Automation Technology Co. Ltd - strain gauge / 4-20 mA / HART - image - 2
Absolute pressure transmitter - PAS100 - Shanghai Powerbuilder Automation Technology Co. Ltd - strain gauge / 4-20 mA / HART - image - 3
Absolute pressure transmitter - PAS100 - Shanghai Powerbuilder Automation Technology Co. Ltd - strain gauge / 4-20 mA / HART - image - 4
Add to favorites
Compare this product


Characteristics

Pressure type
absolute
Technology
strain gauge
Output
4-20 mA, HART
Mounting
flange
Fluid
for gas, for liquids
Material
stainless steel
Protection level
rugged
Applications
process
Other characteristics
compact, combined
Pressure range

Min.: 3 mbar
(0.04 psi)

Max.: 100,000 mbar
(1,450.38 psi)

Precision

0.25 %

Description

Model PAS100 is the compact, reliable, essential absolute pressure transmitter suitable for liquid, gas or steam applications. It is a straightforward and robust device designed for rapid delivery and easy installation and use. Thanks to its rugged design offering high resistance in even the most demanding environments, it is a competitive solution for most applications, including ones in hazardous areas. Overview PAS100 is the new gauge pressure transmitter from ABB, designed to fit markets with standard specifications but subject to fast-to-serve dynamics. Its compact stainless steel housing grants robustness, resistance to humidity and vibration, while incorporating the high visibility display with backlight option. Easiness of use of the touch HMI is enhanced by the Easy Set up feature, a firmware option to easily configure device parameters from the display itself. ABB’s unique technologies like Diaflex (anti-abrasion) or H-Shield (anti hydrogen permeation) come handy if applications demand more. PAS100 offers integral process connections to be combined with a wide selection of adapters and flanges to ensure mechanical fitting to any process point, including the ABB M26 manifold range. Its new QR code option, called Digital Access Diagnostic, details operational messages and enables fast access to useful supporting information on the device and its status with suggestions for correcting errors or faulty conditions, as well as details of possible root causes, thus reducing the reaction time to field occurrences. PAS100: compact, reliable, essential.
