Granules big-bag filling station

powderfor the food industry

1. Pneumatic bag clip device and bracket are installed on the weight sensor for fast and slow filling and high reaction speed weighing system according to the preset weight to ensure high packaging accuracy. 2. The servo motor drives the tray to rise and fall, the lifting speed can be set arbitrarily, filling basically no dust out pollute the environment. 3. Servo motor and servo drive control screw, stable performance and high accuracy. 4. PLC control, touch-screen human-computer interface display, easy to operate. 5. All stainless steel structure; combined or split hopper, very convenient cleaning.6. The filling head is equipped with hand wheel adjustment height, easily realizing a variety of specifications of packaging. 7. The fixed screw installation structure will not affect the properties of the material when filling. 8. The two working modes can be switched, quantitative type or real-time weighing type, quantitative type of fast speed, slightly poor accuracy, real-time weighing type, high accuracy, slightly slow speed. Main Tachnical data Packaging weight: 10kg 12.5kg Packaging accuracy: 10000g,≤±0.1-0.2% Packaging speed: 2-5 times / min Power supply: 3p AC208-415V 50 / 60 Hz Compressed air 6kg / cm2 0.1 m 3 / min Total power: 6.04 kw Total weight: 500kg Hopper capacity: 75L
