- Detection - Measurement
- Position, Speed and Acceleration Measurements
- 3-axis inclinometer
- Shanghai Vigor Technology Development Co., Ltd.
Triaxial inclinometer SST810RS-232MEMSinertial
Add to favorites
Compare this product
Characteristics
- Number of axes
- triaxial
- Output
- RS-232
- Technology
- MEMS, inertial, electrolytic
- Other characteristics
- high-precision, high-resolution, temperature-compensated
- Inclination
Max.: 90 °
Min.: -90 °
- Resolution
0.05 °
Description
Main Features:
- No drift, dynamic tilt measuring
- Lowest cost,high performance
- Built in MEMS tri-axis accelerator and tri-axis gyroscope
- Dynamic repeatability ±0.5°
- Highest refresh rate 100Hz
- Autonomous working, do not need any external auxiliary
- Mounted wherever needed
Application:
- Ship
- Robot
- dynamic GPS assist
- Engineering machinery
- Weapon platform
- Rail transportation
- Photoelectric platform
- Automotive
- Robot
- Power line monitoring, etc.
