Applicable material: SPHC.SPHD,SPCC,SPCD, SPCE, Galvanized coil
Coiler car: Safe and convenient coil loading operation with the assist
Uncoiler shaft synchronizes with feeder machine: Adopting frequency control and gear motor.
Power driven pressing arm: prevents the material from being scattered and to assist the uncoiling
Uncoilling direction: From bottom to up input coil
Straightener roller: Ф48mm x 11 pieces top 6/ bottom5,
Straightener number adjustment way: Worm adjusting by Manual
Straightener roller drive way: Side gear drive
Straightening precision: 51.5mm/m2
Feeding line height adjust wav: Motor-driven, Feeding line height +100mm
Coil width: 50mm-500mm
Material thickness: 0.3mm-3.2mm
Coil weight: 3Ton
Line speed: 20m/min
Line length: 3.2m
Material: CR Steel, HR Steel, Stainless, Aluminum, Copper etc
