1-axis inclinometer ACA610T-N

analogMEMScapacitive

HIGH ACCURACY VOLTAGE INCLINOMETER WITH FULL TEMP-COMPENSATION ★ Single / Dual axis inclination measurement ★ Measure Range :±1~±90° optional ★ Accuracy: 0.003° ★ Wide voltage input: 11.5~36V ★ Wide temperature working: -40~+85℃ ★ IP67 protection grade ★ Highly anti-vibration performance >2000g ★ High Resolution: 0.0007° ★ Temperature drift 0.0005°/℃ ▶ APPLICATION ★ Engineering vehicles automatic leveling ★ Bridge & dam detection ★ Precision instrument level control ★ Medical facilities angle control ★ Underground drill posture navigation ★ Direction measurement based on inclination ★ Geological equipment inclined monitoring ACA610TT-N is a high-precision single/dual-axis inclinometer with full  temperature compensation and voltage output. it adopts a high-precision 24bit A/D  differential converter to ensure the current output linearity of the product, so the user  does not need to make the linearity correction.  it is stable, reliable and easy to use. The system integrates a high-resolution temperature sensor, coworking with the MCU,  processing secondary temperature compensation, by which the full temperature zero driftcan be achieved at 0.0005°/℃, and the accuracy at room temperature can reach 0.003°  for small measure range. The feature of non-contact installation makes this product  compatible for different systems.  It is convenient to install,  easy to operate, robust to resist interference and vibration, it has prominent advantage against its counterparts.
