Single-axis inclinometer ACA618T-N
4-20 mAvoltage outputcurrent output

single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
Add to favorites
Compare this product


Characteristics

Number of axes
single-axis
Output
4-20 mA, voltage output, current output
Technology
MEMS, capacitive, electrolytic, mechanical
Other characteristics
with aluminum housing, high-resolution, high-precision, for pipe jacking machine, geotechnical, rugged, waterproof, economical, for crane, for dumpers, portable, temperature-compensated, IP67, radio telemetry, for geophysics applications, for boreholes, agriculture, anti-vibration, for angle measurement, for the construction industry
Inclination

Max.: 90 °

Min.: 1 °

Resolution

0.001 °

Description

CURRENT INCLINOMETER WITH FULL TEMP-COMPENSATION Single-Axis Inclinometer Temperature drift: 0.0005°/℃ Highly anti-vibration performance >2000g IP67 protection grade Wide voltage input: 9~36V Wide temperature working: -40~+85℃ Product Description ACA618T-N is a high-precision single-axis inclinometer with full temperature compensation and current output. it adopts a high-precision 24bit A/D differential converter to ensure the current output linearity of the product, so the user does not need to make the linearity correction. it is stable, reliable and easy to use. The system integrates a high-resolution temperature sensor, coworking with the MCU, processing secondary temperature compensation, by which the full temperature zero drift can be achieved at 0.0005°/℃, and the accuracy at room temperature can reach 0.003° for small measure range. it output by 4~20mA comparing with voltage output, it can transmit much longer distance as 2km. The feature of non-contact installation makes this product compatible for different systems. Just fix the sensor on the surface of the object to be measured with screws, and then it automatically calculate the inclination angle of the object. It is convenient to install, easy to operate, robust to resist interference and vibration, it has prominent advantage against its counterparts.
