Z-axis inclinometer SCA116Z

digitalMEMSelectrolytic

Z-Axis digital output inclinometer ●Inclination tilt measuring ●Wide voltage input: 9～36V ●Small size :90×40×26mm（customized） ●Output mode RS232/RS485/TTL/ CAN 2.0B (optional) ●Wide temperature working: -40～+85℃ General Description 　SCA116Z is a high accuracy & high performance inclinometer launched by RION company to the Z – Axis measurement application, in industrial applications, it is unpredictable the measured object inclination towards X or Y direction ,which means that the 360-degree horizontal posture may tilt to any one direction, under this application if you use single-axis X or dual-axis XY unable to accurately measure, the Z-axis tilt can meet customer demand, integrated operation of the X-axis and Y-axis data, get the Z-axis tilt angle. 　　SCA116Z built-in high-precision 16bit A / D differential converter, through 5 filtering algorithm, the output interface RS485, RS232, RS422, TTL, PWM are optional.Because of Built in high precision digital temperature sensor that can correct the sensor temperature drift in accordance with the changes of the built-in temperature sensor, to ensure high repeatability of the product in the low-temperature and high-temperature environment. The output frequency response standards up to 18Hz, for higher response frequency Division we can customize according to the user requests. The products are truly industrial-grade products, reliable performance, scalability, and a variety of output options. Suitable for a variety of harsh industrial control environment.
