Single-axis inclinometer HCA516T/HCA526T-CAN2.0A

digitalhigh-precisionIP67

Single-Axis Inclinometer Wide voltage input: 9~36V Wide temperature working: -40~+85℃ Highly anti-vibration performance >2000g IP67 protection class Product Description HCA516T/HCA526T-CAN2.0A is a high accuracy inclinometer developed by RION company, inherit the stability of the SCA series, while the accuracy be effectively improved, and the temperature drift performance with much more excellence , in addition the system with built-in high-precision 16bit A / D differential converter, meanwhile through 5 filtering algorithm, which can measure the angle of sensor output relative to the horizontal tilt and pitch tilt. The output interface CAN 2.0A are optional.Because of Built in high precision digital temperature sensor that can correct the sensor temperature drift in accordance with the changes of the built-in temperature sensor(temperature output are optional), to ensure high repeatability of the product in the low-temperature and high-temperature environment. The output frequency response most up to 100Hz, for higher response frequency Division we can customize according to the user requests. The products are truly industrial-grade products, reliable performance, scalability. Suitable for a variety of harsh industrial control environment.
