Storage
1 * SATA 3.0
1 * M.2 (Key-M, 2280, PCIe x4 NVMe)
Expansion Interface
1 * M.2 (Key-E, 2230, support Wi-Fi+BT)
1 * M.2 (Key-B, 2280, support 4G/5G)
BIOS
- AMI UEFI BIOS
System
- Windows 10/11 64-bit, Linux
I/O Interface
Ethernet
- 2 * Intel® Gigabit Ethernet Controller (up to 2.5 GbE), RJ45
USB
3 * Type-A, USB 3.2
2 * Type-C, USB 3.2 + DP 1.4a
Others
- 2 * Wi-Fi Antenna Hole
Display
Display Interface
1 * DP 1.4a++, max resolution up to 7680*4320@30Hz
2 * DP 1.4a, Type-C, max resolution up to 7680*4320@30Hz
1 * HDMI, Type-A, max resolution up to 7680*4320@30Hz
1 * Micro HDMI IN, HDMI to MIPI CSI
Multiple Display
- Quad
Mechanical & Environment
Dimension
- 173 * 113 * 56mm
Power Input
- DC 12V
Temperature - Operation: 0℃~45℃, Storage: -20℃~75℃
Relative Humidity
- 5%~95% RH (non-condensing)
