ITEM DESCRIPTION detail
Camera 5M/13M, flash 5M/13M, flash
Power and battery battery total capacity 10500mAh "8400mAh,hotswap, 2100mAh backup power
3.8V 3A imput, support hotswap"
3.5*1.35mm, 5V 3A DC in put, type-c support quick charger
FDD: B1,B2, B3,B4, B5, B7, B8, B10, B12,B13, B14, b17, B20, B23, B24, B25, B26
TDD: B38,B39,B40,B41, B66, B71
B34
WCDMA:B1,B2, B5, B8
TD-SCDMA: B34,B35, B36, B37, B38 B39, B40, B41, B42, B43
SPEAKER 1.5 watt
Sensor "1. light sensor
2. compass
3. gravity
4. acceleration
5. baroceptor"
size 275*178*18mm
"Multi-media
(Hardware decoding)" Photo Viewer BMP, JPG, GIF, PNG
Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
language multi language
"interface
in/out port" "1. normal USB*1
3. RJ45*1
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
Pogopin definition "1.16pin back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V OUT)
2. 8pin in bottom; (1USB, 1 RS232, 1 UART, )
casing material ABS/PC
button V+ -, Power, P, F, H
2D barcode module honeywell N3680 optional
UHF reading and write distance 1meter to 10 meter optional
fingerprint module LD-8800-M optional
"standard
accessories
in gift box" "1. USB cable
2. charger( 4-in-1)
3. handstrap
4. handstring
5. white box, no logo"
"optional
accessories" "1. car docking
2. extra battery
3. screen protective film
4. car holder
5. docking station
6. car charger
2. Drapping proof 1.2 meter"
Certification "1. 810G
2. CE,FCC"
Temperature "1. storate temperature -25 to 80 degree
2. operation temperature -20 to 60 degree
