language multi language
Siz 8
Resolutoin 800*1280
brightness Mini classic Max
800nit 1000nit 1100nit
Visual Angle Full View
AA 107.64(H)*172.224(V)
Mode 10 point G+G
Transimitance 90%+
Camera Front5.0M+back 21M PDAF/OTP
SPEAKER 8Ω,1.5Wx1
Mic Sensitivity:-32±2d,Impedence 2.2kΩx1
TF card TF card x1. Max 256GB
button Power, V+,V-,P, F, H
weight 630g
dimension 234*144*16.8
Band TDD-LTE:B34/B38/B39/B40/B41/B66
FDD-LTE:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28
WCDMA:B1/B2/B4/B5/B8
CDMA2000:BC0
TD-SCDMA:B34/B39
Type-C charger/ data transfer x1
3.5mm ∮3.5mm x1
DC DC 5V 3A ∮3.5mm x1
Light sensor Support
distence sensor Support
G-SENSOR Support
Gyroscope sensor Support
Acceleration sensor Support
Air pressure sensor Support
Picture BMP, JPG, GIF, PNG
video MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
Protestion 1. production with IP65,designing with IP67
2. dropping testing 1.2 meter,six side
certification 1. 810G testing report
2. CE, FCC
working temperature ’-20℃~60℃
Storage temperature ’-25℃~80℃
battery inner lithium Bttery
capacity 3.85V / 10000mah
Endurance Play video 18 hours
Standby 240 hours
"Fingerprint
1020A" fingerprint capactiy 150pcs
Response Time <1S
Identification 1:N or 1:1
"2D barcode
NLS-N1" Code 2D:PDF417、QR Code、Data Matrix
1D:Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 2 of 5, Standard 2 of 5, Plessey, MSI-Plessey
