Camera 2M/5M
Power and battery battery capacity 7800mAh
3.5*1.35mm, 5V 3A DC in put
FDD: B1,B2, B3, B4, B5, B7, B8, B28
TDD: B40
B34
WCDMA:B1, B2,B4,B5,B8
GSM: B2, B3, B5, B8"
SPEAKER 1.5 watt
Sensor "1. light sensor
2. acceleration/gravity
"
size 225.6*135.6*13.3mm
weight 0.6kg
"Multi-media
(Hardware decoding)" Photo Viewer BMP, JPG, GIF, PNG
Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
language 语言 multi language
"interface
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
10. micro SD*1
11. SIM card*1"
Pogopin definition "1.16pin back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V)
2. 8pin in bottom; (1USB, 1 RS232, 1 UART, 5V)"
casing material ABS/PC/rubber TPU/aluminum
button V+ -, Power, P, F, H
-------------------------------------------------------------------------------------------------------------------------------------------------
2D barcode module EM 2096 (N3680 in jacket) optional
UHF 900MHz optional
fingerprint support optional
Front NFC under the screen, the distance is 3-5cm, mifare one is optional optional
high precision GPS 0.25-1 meter high precision GPS, support GPS, beidou, glonass optional
accessories
2. charger
3. handstrap optional
4. car holder optional
5. docking station optional
6. car charger optional
7. white box, no logo"
proof rate "1. water proof IP65
2. Drapping proof 1.2 meter"
Certification "1. 810G
2. CE,FCC"
Temperature "1. storate temperature -25 to 80 degree
2. operation temperature -20 to 60 degree
