Camera - 5M/13M, flash - 5M/13M, flash -
Power and battery - battery total capacity 10500mAh - 8400mAh,hotswap, 2100mAh backup power
3.8V 3A imput, support hotswap -
3.5*1.35mm, 5V 3A DC in put - Magnetic charger -
FDD: B1,B2, B3,B5, B7, B8, B12, B20
TDD: B38,B39,B40,B41
B34
WCDMA:B1, B8
TD-SCDMA: B34, B39
SPEAKER - 1.5 watt - -
Sensor - 1. light sensor
2. compass
3. gravity
4. acceleration
5. baroceptor - -
size - 275*178*18mm - -
Multi-media
(Hardware decoding) - Photo Viewer - BMP, JPG, GIF, PNG -
Video Format - MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) -
Audio Format - MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) -
language - multi language - -
interface
in/out port - 1. normal USB*1
2. Micro USB*1
3. RJ45*1
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
8. RS232*1 - -
Pogopin definition - 1.16pin back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V OUT)
2. 8pin in bottom; (1USB, 1 RS232, 1 UART, )
VESA hole 75*75mm or 90*90mm - -
casing material - ABS/PC - -
button - V+ -, Power, P, F, H - -
2D barcode module - honeywell N3680 - optional -
UHF - reading and write distance 1meter to 10 meter - optional -
fingerprint module - LD-8800-M - optional -
standard
accessories
in gift box - 1. USB cable
2. charger( 4-in-1)
3. handstrap
4. handstring
5. white box, no logo - -
optional
accessories - 1. car docking
2. extra battery
3. screen protective film
4. car holder
