Camera 5M/13M
Power and battery battery capacity 7800mAh
3.5*1.35mm, 5V 3A DC in put
FDD: B1,B2, B3, B4, B5, B7, B8, B28
TDD: B40
B34
WCDMA:B1, B2,B4,B5,B8
SPEAKER 1.5 watt
Sensor "1. light sensor
2. acceleration/gravity
size 228*137*13.3mm
net weight 0.6kg
"Multi-media
(Hardware decoding)" Photo Viewer BMP, JPG, GIF, PNG
Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
language 语言 multi language
"interface
in/out port" "1.USB*2
2. Micro USB*1
3. RJ45*1 optional
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
8.RS232*1 optional
9. micro SD*1
10. SIM card*1"
Pogopin definition "1.16pin back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V)
2. 8pin in bottom; (1USB, 1 RS232, 1 UART, 5V)"
casing material ABS/PC/rubber TPU/aluminum
button V+ -, Power, P, F, H
2D barcode module EM2096 optional
UHF 800-930MHz optional
fingerprint support optional
Front NFC under the screen, the distance is 3-5cm, mifare one is optional optional
high precision GPS 0.25-1 meter high precision GPS, support GPS, beidou, glonass optional
face recognition JSK-LA008 Optional
accessories "1. USB cable optional
2. charger
3. handstrap optional
4. car holder optional
5. docking station optional
6. car charger optional
7. white box, no logo "
proof rate "1. water proof IP65
2. Drapping proof 1.2 meter"
Certification "1. 810G
2. CE,FCC"
Temperature "1. storate temperature -25 to 80 degree
2. operation temperature -20 to 60 degree
