support tylus
support thin glove touch - -
Camera - 5M/13M, flash - 5M/13M, flash -
play video 8 hours, working 10 hours charging 4 hours. - 8400mAh,hotswap, 2100mAh backup power
3.8V 3A imput, support hotswap
play video 8 hours, working 10 hours charging 4 hours. -
3.5*1.35mm, 5V 3A DC in put - Magnetic charger -
WWAN - 4G LTE, 3G WCDMA, GSM - 4G Fre:
FDD: B1,B2, B3,B5, B7, B8, B12, B20
TDD: B38,B39,B40,B41
B34
WCDMA:B1, B8
TD-SCDMA: B34, B39
GSM/GPRS/EDGE -
SPEAKER - 1.5 watt - -
Sensor - 1. light sensor
2. compass
3. gravity
4. acceleration
5. baroceptor - -
size - 275*178*18mm - -
Multi-media
(Hardware decoding) - Photo Viewer - BMP, JPG, GIF, PNG -
Video Format - MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) -
Audio Format - MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) -
language - multi language - -
interface
3. RJ45*1
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
8. mini HDMI
Pogopin definition - 1.16pin back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V OUT)
2. 8pin in bottom; (1USB, 1 RS232, 1 UART, )
VESA hole 75*75mm or 90*90mm - -
casing material - ABS/PC/Rubber TPU/aluminum - -
button - V+ -, Power, P, F, H - -
2D barcode module - honeywell N3680 - optional -
UHF - 1meter to 10 meter - optional -
fingerprint module - LD-8800-M - optional -
accessories - 1. USB cable
2. charger
3. handstrap
4. car holder
5. docking station
6. car charger
7. white box, no logo - -
proof rate - 1. water proof IP65
2. Drapping proof 1.2 meter - -
Certification - 1. 810G
2. CE,FCC - -
Temperature - 1. storate temperature -25 to 80 degree
2. operation temperature -20 to 60 degree
