ITEM - DESCRIPTION - detail
support tylus
support thin glove touch -
Camera - 2M/5M -
Power and battery - battery capacity 7800mAh -
3.5*1.35mm, 5V 3A DC in put - Magnetic charger
WWAN - 4G LTE, 3G WCDMA, GSM, Quectel EC25AUGC - 4G Fre:
FDD: B1,B2, B3, B4, B5, B7, B8, B28
TDD: B40
B34
WCDMA:B1, B2,B4,B5,B8
GSM: B2, B3, B5, B8
SPEAKER - 1.5 watt -
Sensor - 1. light sensor
2. acceleration/gravity
-
size - 228*137*12.8mm -
Multi-media
(Hardware decoding) - Photo Viewer - BMP, JPG, GIF, PNG
Video Format - MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)
Audio Format - MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license)
language 语言 - multi language -
interface
in/out port - 1.USB2.0*1 USB3.0*1
2. Micro USB*1
3. RJ45*1 need special cable (optional)
4. bottom pogopin*1, USB and serial
5. back pogopin*1
6. DC*1 3.5*1.35
7. microphone+earphone
8. mini HDMI
9.RS232*1 (need special cable, optional)
10. micro SD*1
11. SIM card*1 -
Pogopin definition - 1.16pin back of cover, include (1USB, 1 RS232, 1 UART, 3.3V, 5V)
2. 8pin in bottom; (1USB, 1 RS232, 1 UART, 5V) -
casing material - ABS/PC/rubber TPU/aluminum -
button - V+ -, Power, P, F, H -
2D barcode module - honeywell N3680 - optional
UHF - 900MHz - optional
fingerprint - support - optional
Front NFC - under the screen, the distance is 3-5cm, mifare one is optional - optional
high precision GPS - 0.25-1 meter high precision GPS, support GPS, beidou, glonass - optional
accessories - 1. USB cable
2. charger
3. handstrap
4. car holder
5. docking station
6. car charger
7. white box, no logo -
proof rate - 1. water proof IP65
2. Drapping proof 1.2 meter -
Certification - 1. 810G
