Intel® Celeron J1900 SBC J1900

quad-coreSATA IIMini PCIe

Quad Cores, Four Threads CPU Socket - Onboard BIOS - SPI 64M Memory - Tech Architecture - DDR3L 1333MHz,1.35 V low voltage JEDEC memor y only Max Capacity - Up to 8GB,non-ECC memory Socket - SODIMM Scoket Display - Graphic Controller - Intel® HD Graphics VGA - Support 1 x standard VGA Port LVDS - Support 1 x 18/24 dual channel LVDS LAN - Controller - LAN1:Rtl8111F GbE LAN WIFI - N/A Audio - Controller - Realtek ALC662 HD Audio Line in/Line out/MIC Super I/O - Controller - ITE IT8728+ITE IT8760 Support System temperature detection,Smart FAN H/W Monitoring - Watchdog Timer - Programmable 1 ~ 255 sec; Support System Reset Smart Fan - 1*3 Pin DC Smart Fan control TPM - Controller - N/A I/O - USB - 4*USB 2.0 PORT(Only for LAN1) 5*USB2.0 Pin Header Serial Port - 6*COM (6 x RS232 option Pin Header ) GPIO - 8 bit programmer,3.3V@24mA Expansion Bus - Mini-PCIe - 1*Mini-PCIe socket, Support 3G Module USIM - 1*Standard SIM socket Storage - SATA - 1*7 PIN SATA II Max.transfer Rate 3Gb/s M-SATA - Full size M-SATA scoket Power - Power Supply - DC-in 12V Power Consumption - Typical PW:10W Environment - Operating Temp. - -0°C ~ 50°C Storage Temp. - -40°C ~ 85°C Operating Humidity - 0% ~ 90% relative humidity(non-condensing) Storage Humidity - 0% ~ 90% relative humidity(non-condensing) Form-Factor - 170 mm * 170 mm Mini-ITX Weight - 0.3kg Certificate - FCC, CE, RoHS compliant
