CPU Package - Onboard
FSB - DMI
BIOS - System BIOS: SPI BIOS, standard CMOS 220mah battery
(Designed with chargeable battery compatible)
Capacity - MAX 8GB
Display - Graphic Controller - Integrated graphic media accelerator
LAN - Controller - LAN1: RTL8111F GbE network, RJ45
Support wake-on-Lan / PXE functions
Audio - Controller - Realtek HD ALC662 audio decode
Super I/O - Controller - ITE8728 SIO
H/W Monitor - Watchdog Timer - 0-255 sec., provide Watchdog program
Temp. Monitor - Support CPU /Motherboard/ HDD temp. monitoring
Support NO power on USB when power-off via jumper selection
Com2 3-wire RS232/485 optional (DB9 integrated GPIO signal
GPIO - 8 bit,provide program,User-defined I/O,3.3V/5V@24mA leve
Expansion Bus - Mini-PCIe - 1*Full-size Mini-PCIe slot, support USB 3G/4G communication module
3G UIM slot
Storage - M-SATA - 1*Full-size m-SATA scoket, Max. transmission rate: 3Gb/s
Power - Power Type - AT/ATX power mode optional,DC9-19V input, support
power reverse and over-voltage protection
F_PANEL - LED - Switch with LED
F_PANEL PB/RESET/HDD LED/PB LED PINHEADER
Environment - Operating Temp. - 0°C ~ 50°C
Storage Temp. - -40°C ~ 80°C
Operating Humidity - 0% ~ 90% relative humidity,non-condensing
Storage Humidity - 0% ~ 90% relative humidity,non-condensing
Formfactor - Dimensions - 134mm*143mm*34.5mm
Weight - 0.78kg
Certificate - FCC CLASS B, CE, RoHS, 3C
