A)Main features:
1.Ricoh Gen5,Ricoh Gen6,Kyocera industrial grey level piezo print head optional;
2.3200mm×2000mm,3200mm×2500mm,3200mm×4000mm super large size optional;
3.More than 30,000 hours of UV-LED curing lamp life;
4.6 area suction platform,the suction material is stronger and adaptable to different materials;
5.Integrated annealed steel frame,the frame is strong and does not deform,and the machine runs more stubly;
6.The two-way car anti-collision device protects the heads from scratches caused by accidents;
7.Dual negative pressure temperature-adjustable subtank and adapt to the temperature of different regions,constant ink viscosity to keep the ink smooth;
8.White ink and color ink have separate ink pressing functions to save ink and reduce costs;
9.Ink level display alarm function for ink tanks,if the ink level is lower than the limit value,it will alarm to avoid production interruption caused by lack of ink.
B)Specification
.Mode:P30
.print size:3200×2000mm(10.5×6.6ft)
.Print head:Ricoh-G5/G6/G5i/Kyocera print head(Optional)
.Print resolution:600×2400dp
.Print mode:Unidirectional and bidirectional
.Ink color:CMYK,Lc,Lm,W,V(Optional)
.Number of heads:2-8 pcs(4-8 colors optional)
.Ink type:Eco-friendly UV curing ink (NO VOC)
.Material thickness:Upto 130mm(5.1in)
.Material type:Rigid and flexible materia
.Material:Glass,acrylic,wood,ceramic,metal,PVC,corrugated board,plastic etc.
.Software:Onyx,PhotoPrint
.Input format:Adobe Postscript Level 3,PDF,JPEG,TIFF,EPS,Al
.Power requiremen:220V/AC(±10%),50/60 Hz;5.8KW
.Printer weight:2100KG
.Printer size:5550mm[L]×2750mm[W]×1500mm[H](17.2ft×9ft×4.9ft)
