Truck test lane Sherlane- 3.5-RSE

for carroller

"Sherlane- 3.5- RSE" scope of supply - Roller set "BPS-Kompakt- 3.5" closed, hot-dip galvanised, welded roller profile - Axle suspension tester "STP-Sherlane-3.5" working with Boge resonance method - Combination control box with motor protection, control electronics, operating elements and lockable main switch, 12 m - pre-wiring between floor assemblies and electrical box Description - Test lane for passenger cars and trucks until 4000 kg axle load - trace at least 800 mm, max. 2200 mm - Safety test lane with control box (withouot display) - roller brake tester and axle suspension tester Roller brake tester BPS-Kompakt-3.5 RSE - Self-supporting, closed roller set: hot-dip galvanised - Traversable axle load: max. 4 t - Roller length: 700 mm - Track width min. / max.: 800 / 2,200 mm - Roller diameter: 205 mm - Roller profile, welded: Friction value dry / wet 0.9/0.8 - Slip roller diameter: 50 mm - Roller centre distance: 400 mm - Test speed/drive capacity: 5 km/h, 2 x 3 kW - testable axle load at 50% braking: 2 t - Supply voltage: 3 x 400 V 50 Hz - Supply line / fuse protection 3 / 4 kW ( 5 kW): 5 x 2.5 mm² (5 x 4 mm²) 3 x 20 A (25A) - Mass per roller set: (W x L x H) 2,320 x 680 x 240 mm Axle suspension tester STP- Standard- 3.5-ME - Floor assembly dimensions: L x W x H 2,320 x 800 x 280 mm - Track width min. - max.: 890 - 2,210 mm - Traversable axle load: 4 t - Testable axle load: 1.2 t - Exciter frequency approx.: 18 Hz - Measurement range max. stroke: 100 mm - Supply voltage: 3 x 400 V 50 Hz - Feed line/fuse protection: 5 x 2.5 mm² 3 x 20 A
