Operating Mode: - Asynchronous/Synchronous, full duplex with control signals
Input/Output Interface: - RS-232-C.
Transmission Line Interface: - ST connector is standard for interfacing with fiber optic duplex cable (SMA option)
Optical Power into a 62.5 Micron Core Optical Fiber: -
10 microwatts, 15 dB power budget @ 850 nanometers (1300nm option)
Receiver Sensitivity: - 300 nanowatts at less than 10-9 bit error rate
Operating Temperature: - 0 °C to 50 °C
Weight: - 4.0 lb (1.8 kg)
Input Power: - 105 to 130 VAC, 50 to 500 Hz, 10 W
Features:
Full duplex Asynchronous/Synchronous 64 Kbps with signals.
6600 ft (2 Km) distance capability
0°C to +50°C operation range
ST connector receptacle
RS232 Interface
