Module multiplexer 2428

fiber opticsmulti-channeloptical

Operation Mode: - Asynchronous, RS422 simplex or full duplex. RS485 half duplex. Input/Output Interface: - RS422/RS485 up to 76.8 Kbps Input/Output Connector: - 37 pin female (DB37) Phase Distortion: - Less than 10% Optical Connector: - ST standard (SMA option) Transmission Distance: - 6600 ft. (2 Km, 5 Km option) Optical Power into a 62.5/125 micron Fiber: - 10µW (50µW option) Receiver Sensitivity: - 0.5 Microwatt @ 10-9 BER System Wavelength: - 850 nm, (1300 nm option) Bit Error Rate: - 10-9 Operating Temperature: - 0 °C to 50 °C Metal Enclosure: - 7.5"X7"X3" (19X17.8X7.cm) Weight: - 3 lbs. 1.36 kg) Rack 6 lbs. (2.72kg) Input Power: - 105 to 130 VAC 60 Hz 230 Volt Version: - 2428V/2458V Model 2428/2458 is an 8 channel communication system providing 8 Bit-Driver links using one optical cable interface. The 2428 provides 8 full duplex RS422 channels for any data rate on any channel(s) up to 76.8 Kbps. The 2458 provides 8 half duplex RS485 channels. The data rate must be set at the factory for data rate up to 76.8 Kbps.
