Chamber furnace TL3 series
tubularrotarytunnel

chamber furnace
chamber furnace
chamber furnace
chamber furnace
chamber furnace
chamber furnace
Add to favorites
Compare this product


Characteristics

Configuration
chamber, tubular, rotary, tunnel
Function
drying, baking
Heat source
combustion, hot air
Atmosphere
controlled atmosphere, air circulating, forced convection
Other characteristics
automatic, stainless steel
Maximum temperature

130 °C
(266 °F)

Max.: 1,000 °C
(1,832 °F)

Min.: 20 °C
(68 °F)

Description

TL-3 model Direct combustion heater consists of 6 components: natural gas burner + inner reservoir + protective casing + blower +fresh air valve + management setup. It is expressly devised for supporting the airflow in the left and right drying area. For instance, in the 100,000 kcal model drying room, there are 6 blowers, three on the left side and three on the right side. As the three blowers on the left side revolve clockwise, the three on the right side turn counterclockwise successively, establishing a cycle. The left and right sides interchangeably serve as air outlets, expelling all the heat generated by complete combustion of natural gas. It is furnished with an electrical fresh air valve to supplement the fresh air in cooperation with the dehumidification system in the drying area. - Advantages/Features 4.1 Uncomplicated configuration and effortless setup. 4.2 Substantial air capacity and slight air temperature variation. 4.3 Resilient stainless steel high-temp-resistant inner reservoir. 4.4 Self-acting gas burner, full combustion, high productivity (Upon installation, the system can independently control ignition+shutdown+automatic temperature adjustment). 4.5 Dense fire-resistant rock wool protective casing to prevent heat loss. 4.6 Fan resistant to high temperatures and humidity, with an IP54 protection rating and H-class insulation rating. 4.7 Alternating operation of fans on the left and right in recurring cycles to ensure uniform heating. 4.8 Automatic supply of fresh air.
