Power converter EIPS series

RS-485CANbidirectional

PCS power conversion system energy storage is a multi-functional AC-DC converter by offering both basic bidirectional power converters factions of PCS power and several optional modules which could offer on/off grid switch and renewable energy access. Ranging from 50kW to 250kW, the PCS converter well fits the requirement of Battery Energy Storage in commercial and industrial applications. Both Energy Storage PCS power conversion system and Lithium-ion Battery System are made by SCU in house. As a hybrid inverter supplier, we could support your PCS battery storage business from power generation, through transmission and distribution, and all the way to users. A Multi-fuctional PCS Power Converter Capacity 50kW power module based modular design achives 50-250kW PCS system Working Mode The pcs power conversion system supports both grid connection mode, off grid mode (microgrid mode) Optional STS Optional STS module support to achive on grid/ off grid seamless transfer Optional DC-DC module Optional DC-DC module offers 250-850Vdc input and provides access to PV and wind Hybrid Inverter Function Could take the place of generator and UPS Modular design 50kW module achieves 50-250kW PCS system, flexible configuration, easy maintenance. Multi-fuctional system On / off grid seamless transfer, able to connect various battery strings, provide access to PV ESS system. Certifications Pass CE LVD EN62477, CE EMC EN61000 EMC, IEC61727, IEC62116. Voltage range: 700-900V Capacity: 50kw, 100kw Size: 600*1000*2000mm Voltage range: 700-900V Capacity: 150kw,200kw, 250kw Size: 1200*1000*2000mm
