Powerline modem module EVSE-PLC
for communicationEthernetRS232

Powerline modem module - EVSE-PLC - Sicon Chat Union Electric Co., Ltd - for communication / Ethernet / RS232
Powerline modem module - EVSE-PLC - Sicon Chat Union Electric Co., Ltd - for communication / Ethernet / RS232
Powerline modem module - EVSE-PLC - Sicon Chat Union Electric Co., Ltd - for communication / Ethernet / RS232 - image - 2
Add to favorites
Compare this product

Characteristics

Type
for communication, powerline
Network
RS232, Ethernet, RS485, CAN bus
Mounting
vehicle-mount, wall-mount

Description

Power line communication modem is suitable for DC charge, and supports conversion of CAN, RS232/485 communication protocol to ISO/IEC 15118 and DIN 70121 standards. It can be installed inside CCS 2 DC chargers or new energy electric vehicles to realize intelligent interconnection between EV and EVSE. Parameter Processor: TI AM3352 Operating system: Linux 4.1.16 SECC interface: CAN, RS 232/485 PLC interface: HomePlugGreenPHY Debug interface: Ethernet port Chip: QCA7000 Operating voltage: 7VDC-30VDC Power consumption: maximum 4W, idle mode 2W Feature PLC modem is exquisite in appearance and easy to be embedded inside EVSE and EV; ISO/IEC 15118, DIN 70121 compliant communication; RS232, RS485, CAN and Ethernet interface to power electronics; Timely handling of abnormal charging process; TUV SUD certified. Application Charge controller in electric vehicle supply equipment (EVSE) Charge controller in plug-in electric vehicles (PEV) Simulators for tests of PEV or EVSE Standards: DIN 70122,ISO 15118 Test Lab: TUV SUD (Verisco)
