Centrifugal pump SPP4
for effluentsacidfor bases

Centrifugal pump - SPP4 - Siebec - for effluents / acid / for bases
Centrifugal pump - SPP4 - Siebec - for effluents / acid / for bases
Centrifugal pump - SPP4 - Siebec - for effluents / acid / for bases - image - 2
Centrifugal pump - SPP4 - Siebec - for effluents / acid / for bases - image - 3
Add to favorites
Compare this product


Characteristics

Technology
centrifugal
Fluid
for effluents, acid, for bases
Operation
electric
Mobility
stationary
Domain
industrial
Applications
metering, outlet
Voltage
230 V
Other characteristics
compact, standard
Flow

Max.: 3.6 l/h
(0.95102 us gal/h)

Min.: 0.08 l/h
(0.02113 us gal/h)

Pressure

2 bar
(29.008 psi)

Power

Max.: 12 W
(0.02 hp)

Min.: 5 W
(0.01 hp)

Width

64 mm
(2.52 in)

Height

77 mm
(3.03 in)

Weight

0.4 kg
(0.88 lb)

Description

Compact, low-flow dosing pump for continuous dosing at low speed or intermittent dosing. Its design has been thought to facilitate the change of hoses, without tools. Ease of use The transparent hinged cover allows the wear condition of the hose to be assessed and replaced quickly and easily if necessary. Materials choice Hoses available in Teknoprene®, Silicon and Viton®. Kit SPP 230V The SPP 24V DC dosing pump is mounted on a converter box that allows you to connect it directly to a standard 230V AC power outlet. A circuit board can be installed for automatic control.
