Ball valve VBF21 seriesleverfor waterflange
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- lever
- Media
- for water
- Body
- flange, brass
- Applications
- for water
- Number of channels
- 3-way
- Other characteristics
- ISO, electromechanical
- DN
Max.: 150 mm
(5.906 in)Min.: 40 mm
(1.575 in)- Pressure
6 bar
(87 psi)- Temperature
Max.: 120 °C
(248 °F)Min.: 1 °C
(34 °F)- Flow rate
Max.: 820 m³/h
(28,958.03 ft³/h)Min.: 25 m³/h
(882.87 ft³/h)
Description
- With flanged connections to ISO 7005
- For chilled or low-temperature hot water in closed circuits
Additional info
SAL..T10 requires mounting set ASK31N
Technical Specifications
Stroke
90 mm
Angular rotation
90°
Leakage rate bypass
0.1 % of kvs
Valve characteristic
Linear
Material, inside set
DN 125: CrNi steel/Rg5
Required mounting set
ASK31N
Leakage rate
0.1 % of kvs
SAL..T10
Δpmax
30 kPa
SQL33.. Δpmax
30 kPa
SQL33../83.. Δpmax
30 kPa
