IP20 variable-speed DC drive G120P-1.1/32A

variable-speedCANopenModbus

Variable speed drive for energy-optimized speed control of pump, compressor and fan motors in building control applications, including: Power Module PM230, Control Unit CU230P-2-BT with screening plate without panel. Additional info When using a screening kit for the Power Module the total height increases as follows: FSA: 80 mm; FSB: 78 mm; FSC: 77 mm; FSD, FSE, FSF: 123 mm. The depth increases when using a BOP-2 by 10 mm, and with an IOP 20 mm. Technical Specifications Operating voltage 400 V Frequency 50/60 Hz Communication Modbus/RTU , RS485/USS , BACnet MS/TP , PROFIBUS (optional) , PROFINET (optional) , CANopen (optional) Overload capacity 110% for 57 sec. and 150% for 3 sec. every 300 sec. Filter type A Degree of protection IP20 Dimensions (W x H x D) 73 x 196 x 223 mm Weight (net) 2.31 kg Product conformity CE , UL , EAC , RCM Standard EN 61800-3
