Digital temperature controller RAZ-ST.011FP-JIP43immersionambient temperature
Add to favorites
Compare this product
Characteristics
- Display
- digital
- Protection level
- IP43, immersion
- Use
- ambient temperature, HVAC
- Other characteristics
- safety
- Maximum temperature
Min.: 15 °C
(59 °F)Max.: 100 °C
(212 °F)
Description
Combination of control thermostat (TR) and safety limit thermostat (STB). Internal scale (TR), internal scale (STB), 2 changeover contacts, failsafe capillary, STB with ambient temperature compensation. Immersion thermostat and wall mounting.
Technical Specifications
Immersion length
100 mm
Protection pocket
PN 10, 100 mm, G ½" LW7
Sensing element
Liquid expansion sensor
Capillary length
700 mm
Reset temperature
Min. 20 Kelvin under the switch-off point
Switching differential
TR: 6 K STB: ±5 K
Digital outputs
1-pin , Potential-free , Changeover contact
Relay outputs
Change-over contact
Relay outputs, number
1
Dimensions (W x H x D)
120 x 106 x 70 mm
