ven-painted iron structure
N° 2 Hydraulic cylinders bore mm.50 per kg 1.900 of crushing force a 100 bar
Servo-assisted hydraulic valves group
N° 1 kit di 1+1 mold + matrix plate for gallette diameter. 90 mm
Adjustable corn dosing unit with ring nut replacement
Mold temperature control through digital thermoregulators
Quick assembly and disassembly system with die plate and single molds
Oil / air heat exchanger
Hydraulic expeller of the finished cakes
Estimated production in about 360 gallons hour
TECHNICAL SPECIFICATIONS
Dimensions : mm. L.700 P.700 h.1500
Total weight : kg. 400
Electric absorption at full capacity Kw 3
Power 380volt trifase+N+T
Cereal tank capacity 5,5 litri
- FEATURES
- Digital thickness gauge adjustment
- Digital cooking time adjustment
Digital cooking temperature adjustment
- Digital adjustment of the machine cycle
- Electronic level control of cereals
