Corn mill GAL 02 serieshydraulicverticalrice
Add to favorites
Compare this product
Characteristics
- Technology
- hydraulic
- Orientation
- vertical
- Product applications
- rice, corn
- Power supply
- 380V three-phase
- Sector
- for the food industry
- Machine length
700 mm
(28 in)- Machine width
700 mm
(28 in)- Machine height
1,500 mm
(59 in)- Machine weight
500 kg
(1,102 lb)
Description
Oven-painted iron structure
N° 2 Hydraulic cylinders bore mm.63 per kg 3200 of crushing force a 100 bar
Servo-assisted hydraulic valves group
N° 1 kit di 2+2 MOLDS + matrix plate for rice cakes diameter 90 mm
djustable corn dosing unit with ring nut replacement
Mold temperature control through digital thermoregulators
Quick assembly and disassembly system with die plate and single molds
Oil / air heat exchanger
Hydraulic expeller of the finished cakes
Estimated production in approx 720 rice cakes hour
