3-axis CNC machining center Caorle MC650
horizontalISO 50HSK-100

3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100
3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100
3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100 - image - 2
3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100 - image - 3
3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100 - image - 4
3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100 - image - 5
3-axis CNC machining center - Caorle MC650 - Sinico Service Srl - horizontal / ISO 50 / HSK-100 - image - 6
Add to favorites
Compare this product


Characteristics

Number of axes
3-axis
Spindle orientation
horizontal
Spindle mount
ISO 50, HSK-100
Number of tool stations
20 tools, 10 tools
Associated functions
drilling
Applications
for bar machining, for tubes
Other characteristics
high-power, with automated loading
X travel

325 mm, 400 mm
(12.8 in, 15.75 in)

Y travel

325 mm, 400 mm
(12.8 in, 15.75 in)

Z travel

600 mm, 700 mm
(23.62 in, 27.56 in)

Rotational speed

Min.: 100 rpm
(628 rad.min-1)

Max.: 5,000 rpm
(31,416 rad.min-1)

Power

Min.: 22 kW
(29.91 hp)

Max.: 30 kW
(40.79 hp)

Weight

16,000 kg
(35,273.96 lb)

Overall length

11,500 mm
(452.8 in)

Overall width

4,600 mm
(181.1 in)

Overall height

2,900 mm
(114.2 in)

Description

Horizontal machining center for machining at the ends, equipped with 2 opposing 3-axis operating units. Numerical control machine capable of simultaneously performing end machining on pipes or bars. Machine designed to be enslaved by an automatic loading system It is able to perform operations of: bezel facing drilling in axis and off axis deep drilling in axis and off axis thread turning with static piece boring General features Min. Workable Length: 20 Mm 200 mm Machinable Diameter Min.-Max. 20 - 330 mm Machine Capacity, In Length 1000 - 12000 mm Max Tapping Size: M33 M33
