Creep-in-compression test stand RWS Series

for materialsmechanical

Can choose environmental equipment,grips,extensometers to meet the need of different materials. testing machines Testing machines Main technical indicator. 1)maximum load10kN,20kN,50kN,100kN,200kN,500kN, can choose load sensor. 2) load measurement error:±1％ reading(from 1/5 of the consumption measurement range). 3)deformation measurement way: LVDT or strain extensometer, the range can choose±1,±3,±5,±10mm. 4) deformation measurement error±0.5％F.S. 5) long-timely control steady of loaddeformation±1％. 6) rate of pull rod0.01-50mm/min. 7) temperaturecan choose following environment chambers&furnaces: split furnace:3001000oC temperature chamber-70+350oC vacuum furnace8001600oC 8) Temperature fluctuation: less than ±2oC. 9) travel of pull rod: 200mm. 10) power supply: three-phase 380V
