Max. FPS - 1920×1080p@60/50fps in → 1920×1080p@60/50fps out
Recording Mode - Hardware Compression, Real-Time Mode
Dimension - 30x50.95 ( mm )
Interface - Minicard (PCIe x1)
Video Input - 1xHDMI, 1xDVI-I, 1xYPbPr
(Through On-Board Wafer Connection)
Display Video Format - YV12, NV12, YUY2, RGB24, RGB32
Video RAW Data Resolution - 1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Recording Video Format - H.264 (Hardware Compression)
Recording Video Resolution - 1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Audio Input - 1×HDMI Embedded Audio
Audio L / R ( Through Wafer Connector )
Audio Format - Stereo / 16-bit / 32000 ~ 48000Hz
Multiple Cards - ∞
SDK - Support API : DirectShow, V4L2, FFmpeg, Gstreamer
Support Language : C++, C#, .NET, Visual Basic, Qt, Delphi
OS Support - Windows 7 / Windows 8 / Windows 8.1 / Windows 10
Linux 2.6.14 or Higher ( 32-bit and 64-bit )
