Vibrating welding machine VSP 416-L

semi-automaticbenchtopfor plastics

The VSP 416 L vibration welder is designed and manufactured using state-of-the-art technologies (3D CAD, CNC). This technology is used to weld complex shape thermoplastic material pieces, or materials that cannot be welded using other conventional welding technologies (ultrasound – hot blade welding). The vibration is linear. A particular mechanism patented by Sirius achieves a linear movement through the rotation of a shaft driven by a brushless motor. The mechanical and electrical solutions available create optimal operating conditions with ample adjustment possibilities, making the welder ideal for most welding applications. The welder has a highly robust structure. The base and column are painted steel. The motor that drives the central shaft is the brushless type. Movement of the vibration head is pneumatic, controlled by a proportional valve and takes place on high precision prismatic guides with excellent mechanical features. One of the most important features of this welder is the cycle control system managed entirely by a MICROPROCESSOR. ITALIAN QUALITY
