Bevel gear reducer RP2 seriesparallel-shafthollow-shaft5 - 10 kNm
Add to favorites
Compare this product
Characteristics
- Type
- bevel
- Shaft orientation
- parallel-shaft
- Shaft configuration
- hollow-shaft
- Torque
- 5 - 10 kNm
- Mounting
- shaft-mounted
- Performance
- for heavy loads
- Applications
- for heavy-duty applications
- Rotational speed
Max.: 2,800 rpm
(17,592.92 rad.min-1)Min.: 900 rpm
(5,654.87 rad.min-1)- Power
140 kW
(190.35 hp)
Description
High Versatility
7 sizes that offer a wide range of possible mounting positions.
High Performances
Max input power 140 kW.
Max torque 10000 Nm.
Ratios up to 30/1.
High Reliability
Sturdy cast iron housing for heavy duty applications.
High resistant gears made in top quality steel.
Largely proportioned bearings.
High quality sealing for improved leaking prevention.
Optional Accessories
Hollow output shaft with taper lock device
Backstop device
