Thermoformed tray 24-204

Conductive material in volume, charged in carbon powder. Standard material for the creation of conductive packaging. Features CONFORMS TO EN 61340 SURFACE RESISTANCE Rpp < 10^4 Ohm THICKNESS 0,6mm 0,8 mm 1,2 mm 1,5 mm 1,8 mm 2,2 mm 3 mm 4 mm 5 mm 6 mm COLOR Black Product specifications Material: conductive carbon-loaded PS Colour: black Dimensions: see drawing Thickness: from 0.6 mm to 6 mm before thermoforming Shelf life: permanent Heavy metals: < 100 ppm (RoHS compliant) Electrical properties (raw material before forming) Surface resistance: < 104 Ω Volume resistance: < 104 Ω Decay time: < 0.2 sec Electrical properties are in compliance with the requirements of norms IEC 61340-5-1 and ANSI/ESD 20.20 (including IEC EN 61340-5-3:2010 and ANSI-ESD_S541-2008). Material properties Maximum temperature of use: 60°C / after thermoforming Tensile strength: 23 Mpa (ISO 527) / before thermoforming Yield strength: 28 Mpa (ISO 527) / before thermoforming Elongation at break: 20% (ISO 527) / before thermoforming Elongation at yield: 8% (ISO 527) / before thermoforming
