Wall-mounted fan THT/CL series
reversibleIP55axial

wall-mounted fan
wall-mounted fan
Add to favorites
Compare this product


Characteristics

Type
wall-mounted, reversible, IP55
Configuration
axial
Function
fume exhaust, anti-corrosion
Supply voltage
230VAC, 400 VAC
Drive mechanism
with asynchronous motor
Material
cast aluminum
Air flow

Max.: 199,030 m³/h
(7,028,678.118 ft³/h)

Min.: 1,520 m³/h
(53,678.293 ft³/h)

Diameter

Max.: 1,735 mm
(68.307 in)

Min.: 490 mm
(19.291 in)

Rotational speed

Max.: 2,940 rpm
(18,473 rad.min-1)

Min.: 455 rpm
(2,859 rad.min-1)

Noise level

Max.: 90 dB

Min.: 31 dB

Description

400 ºC/2h and 300 ºC/2h tubular axial extractor fans with long casing and external terminal boxes Tubular axial extract fans with long casing for immersed operation in fire risk zones. Fan: • Tubular casing in sheet steel with external terminal box (Cable box) and inspection hatch. • Variable angle impeller made of cast aluminium. • Approved in accordance with standard EN 12101-3, with certifications no.: 0370-CPR-0305 (F400) and 0370-CPR-0973 (F300). • Airflow direction from motor to impeller. Motor: • Class H motors for S1 continuous operation and S2 emergency use. With ball bearings, IP55 protection and 1 or 2 speeds, depending on model. • Motors with IE3 efficiency for powers equal to or greater than 0.75 kW, except single-phase, 2-speed and 8-pole. • Three-phase 230/400 V 50 Hz (up to 3 kW) and 400/690 V 50 Hz (powers greater than 3 kW). • Maximum temperature of air to be carried: S1 -25 ºC +40 ºC continuous service, also suitable for warm climates with temperatures up to 50 ºC. S2 operation, 300 ºC/2h, 400 ºC/2h. Finish: • Anti-corrosive finish in polyester resin, polymerised at 190 ºC, after degreasing with phosphate-free nanotechnology treatment. Available versions: • THT: Tubular axial fans with short casing. On request: • Airflow direction from impeller to motor. • 100% reversible impellers.
