Echometric testing device KIT MCHA

concreteultrasonicpiezoelectric

All-in One system is a rugged and reliable equipment with various dedicated piezoelectric sensors and probes. All-in One is characterized by an A/D board multichannel and selectable sampling rates from 10KHz to 6.25MHz (up to 12.5MHz single channel). All acquired signals are displayed, computed and memorized directly on tablet pre-installed software. Connection between All-in One system and tablet via Wifi. PRODUCT PLUS • 3 probes system • Drastic reduction of acquisition time survey • Smart probes including signal generation and active pre-amplification • DDistance between pipes up to 3m • Acquisition unit with high dynamic range and low electronic noise • Ultrasonic contact probes (55- 20KHZ) triggered hammer, dedicated software • Rugged and reliable equipment • Pulse echo & low strain method, elaboration software included • Fully respects main international standard guidelines APPLICATIONS • Verification of concrete elements on-site • Analysis of diaphragms and foundation piles • Seismic cross-hole test • According to the standard guideline: ASTM D676O-16. • Simultaneously cross-hole measurements along three paths in the pile foundation. • Synchronization impulse using an encoder • The results can promptly be printed • High power transmitter and high sensitive active-type piezoelectric receivers (Selectable: 80KHz, 50 KHz).
