Engineering software MBD

CADcontrolproduct documentation

Define, organize, and publish 3D annotations, including 3D model data in industry-standard file formats. Why Choose SOLIDWORKS MBD? SOLIDWORKS® Model-Based Definition (MBD) lets you define and organize 3D dimensions, tolerances, datums, notes, Bills of Material (BOMs), and other annotations; customize publishing templates for manufacturing, such as Part or Assembly Specifications, Request for Quote (RFQ), and Incoming Inspection Reports. You can also publish to widely accepted formats, such as eDrawings®, STEP 242, and 3D PDF for clear 3D communications. For easier adoptions of the model-based practices, several convenient capabilities have been included in every seat of SOLIDWORKS Standard. With SOLIDWORKS Standard, you can annotate a 3D part or assembly, organize the 3D definitions with annotation views and communicate in eDrawings all directly in 3D. Define 3D Annotations SOLIDWORKS MBD helps you define feature-based annotations in Parts and assemblies (DimXpert), and import 3D annotations from common CAD formats for more efficient design. Organize 3D Annotations When the number of 3D annotations becomes too many, you can show and hide annotations automatically as a model rotates, capture comprehensive settings with 3D views similar to visual bookmarks, compare 3D annotation differences between revisions to capture subtle but critical differences Publish 3D Data with Annotations and Views SOLIDWORKS MBD helps you communicate directly in 3D. If you like 3D PDF, the software can customize the templates, control accuracies and PDF sizes, publish BOM tables and notes, attach multiple files upon publishing, create and attach STEP242 files
