CNC milling-turning center Genymab 630 L

horizontal4-axis5-axis

• Orthogonal linear axis with consequent Y stroke: 400mm • Reconstituted granite monobloc base • Fixed support (non-rotating) for turning tools: o turning tool support at 45° to resume cutting forces • Head rigidity allows to machine with long boring bars • Elaborated machining: grooves, plunge milling, • External gears with module mill or mother mill • Internal gear by slotting EQUIPMENT B axis: 144 positions with Hirth teeth at 2,5° Compact milling spindle 8000 rpm 28 positions Tool magazine capacity 3 jaws self-centering chuck 1 set of 3 hardened jaws 1 set of 3 "soft" jaws Chip conveyor 7 bars coolant system with 30µm filter cartridge Full protection with sliding front door and security lock Automatic volumetric greasing interior lighting Sliding and swiveling operator console, with 1 or 2 hanwheels Spindle power display (percentage of available power) OPTIONS: Continuous B axis (5 axis) 1° Hirth teeth for 360 milling spindle positions Compact milling spindle 12 000 rpm Precision linear scales MK5 hydraulic tailstock (on table or front bed) Tailstock automated motion on front bed VDI 40 Automatic turret, 12 stations on front bed Turning Spindle alternatives: Spindle 8", A2, bore Ø105mm Spindle 11", A1, bore Ø112mm Electro-spindle 8", A1, bore Ø73mm Electro-spindle 8", A2, bore Ø105mm Electro-spindle 11", A1, bore Ø122,5mm Turning sub spindle alternatives: all above electrospindles medium or high pressure coolant system: 14 bars, 35 bars... 50 sations automated tool changer (28 + 22) workpiece ejector controlled by M function workpiece recovery system (on sub spindle) workpiece probe tool probe Self centering steady rest, SLU type, sizes 1 to 4
