Ultrasonic flowmeter SWU801
volumefor waterfor oil

Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 2
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 3
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 4
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 5
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 6
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 7
Ultrasonic flowmeter - SWU801 - Soway Tech Limited - volume / for water / for oil - image - 8
Add to favorites
Compare this product


Characteristics

Technology
ultrasonic
Type
volume
Fluid
for water, for oil, for wastewater
Pipe diameter
DN100 - 4", DN15 - 1/2", DN300 - 12", DN175 - 7", DN50 - 2", DN80 - 3", DN125 - 5", DN40 - 1"1/2, DN25 - 1", DN60 - 2"1/4, DN32 - 1"1/4, DN1200 - 48", DN65 - 2"1/2, DN275 - 11", DN200 - 8", DN225 - 9", DN90 - 3"1/2, DN250 - 10", DN150 - 6"
Installation
clamp-on, wall-mounted
Material
stainless steel, plastic
Communication
4-20 mA, RS485, Modbus, RS-232
Supply voltage
36 VDC
Protection level
IP65, IP68
Applications
HVAC, for water treatment, irrigation
Other characteristics
energy meter
Volumetric flow rate

Max.: 16 ft³/s

Min.: 0 ft³/s

Process temperature

Max.: 80 °C
(176 °F)

Min.: -40 °C
(-40 °F)

Precision

1 %

Repeatibility

0.2 %

Description

SWU801 is a wall-mount,clamp- on type ultrasonic flow meter which uses the transfer time technology. Designed using FPGA chip and low-voltage broadband pulse transmission. Both Clamp on type sensors and Insertion type sensors are available. SWU801 has a 240*128 back lit LCD with 4 line menu display and also the clear, user-friendly menu selections make flow meter more simple and convenient to use.Daily, monthly and yearly totalized flow. Parallel operation of positive, negative and net flow totalizes with scale factor(span) and BTU Capacity. While the output of totalize pulse and frequency output are transmitted via relay and open collector. SWU801 could add the RTD model and temperature sensor become an energy meter tomonitoring the energy use, help to save the energy. Application: SWU801 ultrasonic flowmeter widely application in HVAC,water treatment, irrigation.
