Lubricated vacuum unit BluVacCompact

industrialcompact

BluVacCompact – Vacuum units with integrated separator - second generation Designed for the extraction of air-water mixes Energy-saving vacuum generation and energy-saving water discharge due to patented speed-controlled bi-functional pump Pressure level monitoring with pressure sensor in the separator Separation of air and water by integrated separator made from stainless steel Media Gas/water mixtures Motor 2,8 – 4,3 kW (7 – 67 Hz), 3~Mot Material design Stainless steel Cast iron Copper alloy Suction connection G 1 1/2 Pressure connection SAE 1 1/4 Sealing Mechanical seal Dimensions (WHD) 600 – 656 x 385 x 370 Applications Further applications General controlled vacuum generation Plastics industry Vacuum calibration for the manufacturing of plastic profiles Production of polystyrene parts (EPP / EPS) Chemical industry Distillation / separation of liquids Recovery of condensates (solvents) Advantages Compact design Highly efficient by generating a demand-based vacuum Decentralised systems, smart control, easy handling As easy to install as existing vacuum pumps
