BluLine BL – Vacuum units with side channel compressors from the VB series
Designed for the extraction of moist air
Energy-saving vacuum generation due to speed-controlled side channel compressor from the VB series
Pressure level monitoring with pressure sensor in the suction connection
Moisture-optimized bearing area: Significantly longer service life than conventional side channel compressors
Media
Dry and humidified gases
Motor
1,5 – 4,3 kW (10 – 70 Hz), 3~Mot
Material design
Aluminium
Suction connection
VB-140: G 1 1/2
VB-210: G 2
VB-415: G 2
Pressure connection
VB-140: G 1 1/2
VB-210: G 2
VB-415: G 2
Sealing
Radial seal ring
Dimensions (WHD)
341 – 486 x 330 – 407 x 287 – 381
Applications
Further applications
General controlled vacuum generation
Plastics industry
Vacuum calibration for the manufacturing of plastic profiles
Advantages
Highly efficient by generating a demand-based vacuum
Decentralised systems, smart control, easy handling
As easy to install as existing vacuum pumps
Longer service life compared to conventional side channel blowers due to optimized storage under moist conditions
